XTS3060 handheld handling clock

XTS3300 handheld time calibration device is a portable, high-precision, and reliable handheld mobile frequency time source independently developed by Beijing Xinsheng Technology. This product can track and lock Beidou satellite signals outdoors, and after taming the built-in time keeping unit, calibrate the NTP network time server in the computer room by outputting two 1PPS second pulses and TOD signals. This innovative design solves the technical problem of fully enclosed computer rooms being unable to obtain Beidou satellite signals in one fell swoop, while significantly improving the safety of Beidou satellite synchronization.

major function

Portable: can be easily moved on-site

Synchronization: Built in NTP network port, capable of synchronizing clocks of tens of thousands of clients, IP-based devices, and other devices

Transportation: After taming the constant temperature crystal oscillator in the field, the accurate time and frequency source can be transported to the fully enclosed machine room

Automatic switching: GPS Beidou can be set as the main backup system at will, and it also has the function of automatic switching for reference source faults

Punctuality: optional with high-performance constant temperature crystal oscillator or rubidium atomic clock, precise timing can still be achieved after satellite signal interruption
